Astro/MDX Directory Tree Component

Tue Nov 07 2023

I got tired of copying and pasting weird ASCII characters in order to write out directory trees so I wrote an Astro component to convert YAML into a format that looks like the output of the Linux tree command!

I’ll show you how to get from this:

project:
  - config:
    - __init__.py
    - asgi.py
    - settings.py
    - urls.py
    - wsgi.py
  - manage.py
  - Pipfile
  - Pipfile.lock

to this:

{
  "project": [
    {
      "config": [
        "__init__.py",
        "asgi.py",
        "settings.py",
        "urls.py",
        "wsgi.py"
      ]
    },
    "manage.py",
    "Pipfile",
    "Pipfile.lock"
  ]
}

to this:

└── project/
    ├── config/
    │   ├── __init__.py
    │   ├── asgi.py
    │   ├── settings.py
    │   ├── urls.py
    │   └── wsgi.py
    ├── manage.py
    ├── Pipfile
    └── Pipfile.lock

This is the result of running the command django-admin startproject config . inside a directory called project.

I won’t go into too much detail about how the code for this works. There are plenty of great resources on how to pretty print directory trees.

This Real Python article is very thorough if not a bit overkill.
This Stack Overflow thread has a bunch of great information as well.

All I really did was rewrite the general function outline in TypeScript and adapt it to take in an object as input instead of a filepath.

Step One: Convert YAML String to JavaScript Object

I used the JavaScript package js-yaml to convert a YAML-formatted string to an object. Unfortunately, the load function from this package returns an object of type unknown so I had to define and use my own types.

import { load as loadYaml } from "js-yaml";

// union of all possible *individual* node types
type SingleNode = string | number | boolean | undefined | TreeNode;

// recursive type for tree of nodes
interface TreeNode {
  [key: string]: SingleNode[] | null;
}

const yamlString = `
root:
  - sub1:
    - file.txt
  - sub2:
    - file.txt
`;

const yamlObj = loadYaml(yamlString) as TreeNode;

Step Two: Use Object to Create Tree Representation

This isn’t meant to be an introduction to recursive functions, so I won’t walk through each line of the code. Hopefully the included comments are enough for folks newer to recursion to follow along.

const createTree = (yamlObj: TreeNode): string => {
  // "header" strings
  const PIPE = "│   ";
  const BLANK = "    ";

  // node "prefix" strings
  const ELBOW = "└── ";
  const TEE = "├── ";

  const res: string[] = [];

  // inner recursive function to build tree strings
  const traverseTree = (node: SingleNode, header = "", last = true): void => {
    // is the node an object?
    if (typeof node === "object") {
      // all object nodes should have a single key
      for (const key in node) {
        res.push(`${header}${last ? ELBOW : TEE}${key}/`);

        const children = node[key]; // SingleNode[] | null
        // check that children !== null
        if (children) {
          for (let i = 0; i < children.length; i++) {
            const child = children[i];
            // build up header string
            const h = header + (last ? BLANK : PIPE);
            // is this node the last child of a parent?
            const l = i === children.length - 1;
            traverseTree(child, h, l);
          }
        }
      }
    /**
     * else if node is (a):
     * - string
     * - number
     * - boolean
     * - undefined
     */
    } else {
      res.push(`${header}${last ? ELBOW : TEE}${node}`);
    }
  }

  traverseTree(yamlObj);

  return res.join("\n");
};

This might save me some time in the long run, but honestly it was just fun to build. If you or a loved one ever wants to display a directory tree, consider using a free tool someone else already built!

View the MDX for this page or submit an issue if you noticed any errors!
